Linux Media Players for Digital Signage | Stable & Secure Performance
Linux Media Players in firmChannel’s digital signage platform refer to the use of Linux-based devices to run and manage digital signage content. These media players leverage the robust capabilities of the Linux operating system to provide a stable, secure, and flexible solution for digital signage deployments.
CMP200-10 Linux Based Player
Technical Specifications
| Specification | Details |
|---|---|
| Model | CMP200-10 |
| CPU | Intel® Processor N250, TDP 6W |
| Graphics | Intel® Graphics |
| Memory | 8GB |
| Storage | 250GB SSD |
| Wireless Data Network | Intel® Wi-Fi 6E AX211 (Gig+), Bluetooth 5.3 |
| LAN | 1 x Realtek Ethernet Controller RTL8125BG-CG, 2.5G |
| Audio | Realtek ALC3251 |
| Front(Side) I/O Ports | 1 x USB 3.2 Gen2 Type-C 2 x USB 3.2 Gen2 Type-A 1 x 3.5mm Headset Jack 1 x Kensington Lock |
| Back I/O Ports | 1 x USB 3.2 Gen2 Type-C w/ DisplayPort 1.4 2 x USB 3.2 Gen2 Type-A 1 x USB 2.0 Type-A 1 x HDMI 2.1 (TMDS) 1 x DisplayPort 1.4 1 x RJ45 LAN 1 x DC-in |
| Power Supply | 19VDC, 3.42A, 65W Power Adapter |
| Dimensions (W x D x H) | 135mm x 115mm x 36mm |
| Weight | 470g |
| Accessories | VESA Bracket and Screws |
| Operating System | Debian 12 |
CMP100-10 Android and Linux Player
A compact, fanless 4K player for digital signage. An 8-core processor with a 6 TOPS AI accelerator, two HDMI outputs and an HDMI input, in a compact metal enclosure. It runs Android 14, or Debian 12 Linux as an option, and ships with a VESA mount plate for fitting behind a display.
- Android 14, or Debian 12 Linux (optional)
- 8-core Rockchip RK3576 with a 6 TOPS AI accelerator
- 4 GB memory, 64 GB storage
- Two HDMI outputs (up to 3840 x 2160 at 60 Hz) and an HDMI input
- Video decoding up to 8K at 30 fps
- Gigabit Ethernet, Wi-Fi 802.11ac and Bluetooth 4.2
- Fanless metal enclosure, 160 x 107 x 36 mm (6.3 x 4.2 x 1.4 in)
- Scheduled and automatic power on
Ideal for menu boards, wayfinding, lobby screens and information displays.
Technical specifications
| Specification | Details |
|---|---|
| Processor | Rockchip RK3576, 8-core: 4x Cortex-A72 + 4x Cortex-A53; 6 W TDP |
| AI accelerator | NPU, 6 TOPS; INT4, INT8, INT16, FP16, BF16 and TF32 |
| Graphics | Mali-G52 MC3; OpenGL ES 3.2, OpenCL 2.0, Vulkan |
| Memory | 4 GB LPDDR4X, onboard |
| Storage | 64 GB eMMC, onboard |
| Operating system | Android 14 (Debian 12 optional) |
| Video decoding | Up to 8K at 30 fps: H.264, H.265, VP9, AVS2 |
| Video encoding | Up to 4K at 60 fps: H.264, H.265 |
| Display outputs | 1x HDMI 2.0 up to 3840 x 2160 at 60 Hz (HDCP 2.3); 1x HDMI 1.4 up to 2560 x 1600 at 60 Hz (HDCP 2.2) |
| Video input | 1x HDMI 2.0 in, up to 3840 x 2160 at 60 Hz (HDCP 2.3) |
| Network | 1x Gigabit Ethernet (RJ45); Wi-Fi 802.11ac, 2.4 and 5 GHz; Bluetooth 4.2; external antenna |
| USB and serial | 3x USB 3.2 Gen 1, 1x USB 2.0 OTG, 1x RS-232 |
| Audio | 1x headset jack (microphone in and audio out) |
| System | Hardware watchdog timer; auto power on; real-time clock with power-on schedule per day of the week |
| Power | 12 V DC, 2 A; lockable DC input; AC power adapter included |
| Power consumption | 8.5 W idle; 16.3 W full load |
| Enclosure | Fanless metal, black; 160 x 107 x 36 mm (6.3 x 4.2 x 1.4 in) |
| Weight | Unit 0.67 kg (1.48 lb); packaged with mount 1.3 kg (2.87 lb) |
| Temperature | Operating 0 to 45 °C (32 to 113 °F) with 0.7 m/s airflow; storage -20 to 75 °C (-4 to 167 °F) |
| Humidity | 95% at 45 °C, non-condensing |
| Mounting | VESA mount plate and screws included: 75 x 75 and 100 x 100 mm |
| Certifications | CE, FCC Class B, UKCA, RoHS |
| Warranty | 1 year, return to depot |
Connections
Front
- Power button
- Recovery button
- 3x USB 3.2 Gen 1
- USB 2.0 OTG
- RS-232 serial
Rear
- Wi-Fi antenna
- Headset jack
- 2x HDMI outputs
- HDMI input
- Gigabit Ethernet
- 12 V DC in (lockable)
In the box
- CMP100-10 media player
- VESA mount plate and screws
- Wi-Fi antenna
- AC power adapter and power cable
The VESA mount plate fits 75 x 75 and 100 x 100 mm patterns, so the player can sit out of sight behind the display.
Linux Media Players for Secure Digital Signage Deployments
firmChannel’s digital signage platform offers robust support for Linux-based media players, providing a stable, secure, and flexible solution for your digital signage needs. Linux media players are renowned for their reliability, open-source flexibility, and strong security features, making them an excellent choice for a variety of digital signage applications.
Unmatched Stability & Security for Reliable Digital Signage
- Reliable Performance: Linux media players are known for their stable and reliable performance, ensuring that your digital signage content is delivered consistently without interruptions.
- Strong Security: The Linux operating system offers strong security features, protecting your digital signage network from unauthorized access and cyber threats. Regular security updates and patches further enhance the security of your deployment.
Extensive Hardware Compatibility for Flexible Signage Applications
- Diverse Hardware Support: Linux supports a wide range of hardware, making it a versatile choice for diverse digital signage applications. Whether you need a compact media player or a high-performance device, Linux can accommodate your requirements.
- Seamless Integration: Linux media players integrate seamlessly with firmChannel’s platform, ensuring smooth and efficient operation of your digital signage network.
FAQ
Frequently Asked Questions (FAQs)
What types of Linux devices are compatible with firmChannel’s platform?
How does using Linux media players benefit my digital signage network?
What kind of content can I display using Linux media players?
Are there specific technical requirements for using Linux media players with firmChannel’s platform?
Request a demo today!
Enhance your digital signage network with the stable, secure, and flexible capabilities of Linux media players supported by firmChannel’s platform. Request a demo today to discover how our solutions can elevate your digital signage strategy.
